>产品与方案>Optical Imaging System and Products>STRUCTURE LIGHT
| sensor |
1/4"， WXGA（1M pixel） CMOS Sensor |
|
signal system |
720p/30~VGA/30~QVGA/30 |
| image resolution |
650 TV lines |
|
lens |
FF，EFL is 3.45mm，FN 2.0 |
| FOV（D） |
66° |
| S/N |
S/N ≥50dB |
| lowest illumination |
0 LUX (with IR light on) |
| image coding |
H.264 |
|
video output |
WIFI output，support IEEE802.11N/B/G |
| mating APP |
Android / IOS |
| AWB |
automation |
|
AE control |
automation |
|
image performance |
mirror image and vertical overturn |
|
stock temperature |
-20～60 °C |
|
operating temperature |
0～50 °C (recommended) |
|
power |
DC 5 V / USB built-in battery |
|
battery |
3.7v，950 mAH |
|
max power consumption |
2.5W |
|
weight |
80g |
|
deimension |
55.2×13×94.2 mm |
