>产品与方案>Optical Lens Sets>CCTV Lens
| P/N | Sensor Size | Resolution | FNO |
Focal Length( mm ) |
FOV ( D ) | TTL (mm) | Mount | ||||
|
SYC7060 |
3/4" | 5MP | 1.6 |
12 |
56° | 60.0 | CS | ||||
| SYC7062 | 3/4" | 5MP | 1.6 |
16 |
43.5° | 58.6 | CS | ||||
|
SYC7061 |
1" | 5MP | 1.6 |
16 |
60.25° | 77.4 | CS | ||||
| SYC7065 | 1" | 4MP | 1.6 |
20 |
42.92° | 71.4 | CS | ||||
| SYC7049 | 3/4" | 5MP | 1.6 |
25 |
27.5° | 46.8 | CS | ||||
| SYC7064 | 4/3" | 8MP | 1.6 | 25 | 41.1° | 96.0 | C | ||||
|
SYC7067 |
1" | 5MP | 1.8 |
25 |
35.4° | 73.0 | CS | ||||
| SYC7068 | 4/3" | 8MP | 1.8 |
30 |
43.0° | 100.4 | C | ||||
|
SYC7050 |
1" | 5MP | 1.4 |
35 |
25.2° | 52.8 | CS | ||||
| SYC7079 | 1/1.8" | 8MP | 1.6 |
11~40 |
45.2°(W)-13.9°(T) | 101.9 | CS | ||||
| SYC7080 | 1/1.8" | 8MP | 1.6 |
3.8~16 |
124°(W)-33.5°(T) | 87.7 | CS | ||||
| SYC7088 | 1/1.8" | 8MP | 1.0 | 8.0~25 | 60.92°(W)-20.11°(T) | 106.85 | CS | ||||
